    We undertake the work of doing PLC programming alone for various brand of PLCs. We also do programming of HMIs and SCADA development. During this we do the integration of various other automation components like VFDs, servo drives, sensors and safety systems.

    GENERAL PLC PLC H3U

    • All-in-one CPU, power supply and I/O.
    • Basic instruction: 100ns/instruction.
    • Program capacity: 64K steps.
    • Device memory
      • Auxiliary Relays 9216 points
      • Timers 512 points
      • Counters 256 points
      • Data Registers 9552 points
      • File Registers 32768 points
    • High-speed inputs: 200kHz
    • High-speed outputs: 200kHz(Standard Model) 500kHz(Motion Control Model).
    • Interpolation: two-axis arc and straight line, three-axis straight line(Motion Control Model), spiral line(Motion Control Model)
    • Three-axis electronic cam(Motion Control Model).
    • Supports MODBUS-RTU & MODBUS-TCP & CANlink/CANopen modes.
    • Maximum of 192 digital I/O(local).
    • Programming language: Ladder, Instruction list, SFC

    GENERAL PURPOSE MICRO DRIVE MD 310

    • 4 to 18.5kW.
    • Wide operating voltage : Three Phase 380VAC, 323 to 456VAC.
    • Onboard MODBUS & optional CANlink.
    • Open loop V/F & SVC control; Staring torque of 150% at 0.5Hz(SVC) and 100% at 1Hz(V/F) ; Automatic torque boost.
    • Simplified parameter for easy start up
    • 4-Independent S-Ramps
    • Output frequency 500Hz
    • Overload : 150% for 60 Sec & 180% for 3 Sec
    • In-Built Dynamic braking unit

    HIGH PERFORMANCE UNIVERSAL DRIVE MD 520

    • 3 Ph 380-480 Vac: 0.4 to 500 kW.
    • 3 Ph 200-240 Vac: 0.4 to 90 kW.
    • 1 Ph 200-240 Vac: 0.4 to 2.2 kW.
    • Operation in high ambient temperatures – up to 50degC.
    • Built-in DC reactor (400 V: 18.5 kW and above; 200 V: 11 kW and above.
    • Conformal coated PCBs compliant to 3S2 and 3C3 environments.
    • Complies to efficiency level IE2 as defined in IEC 61800-9-2.
    • Control modes: V/f for induction motor, Sensorless vector control (SVC), closed loop vector control (FVC) for both induction (asynchronous) and PMS motors.
    • Starting torque; 150% at 0.25 Hz for SVC; 180% at 0 Hz for FVC.
    • Communication options: Modbus-RTU, PROFIBUS-DP, CANopen, CANlink, PROFINET, EtherCAT, Ethernet/IP.
    • Brake control logic; inbuilt brake resistor upto 90kW.
    • Application dedicated functions: Centre winder, Textile wobble control, Master slave function. 4 motor parameter sets.
    • Bipolar analog input as standard (-10 to +10 V); PTC input as standard.
    • Output frequency: 599 Hz.
    • Encoder feedback (option): Incremental (HTL, Line Driver), Resolver, Serial encoder.

    SINGLE AXIS SERVO SV660P-PULSE TYPE,SV660P-ETHERCAT

    • Ultra-fast 4.5 kHz current loop.
    • Safe Torque Off – SIL3.
    • High speed EtherCAT communications – 125 μs.
    • 23 bit High resolution feedback encoder.
    • Short output winding Standard, built-in, short output winding ensures safe braking if the drive is unexpectedly disabled – even in the case of a failure in the motor holding brake.
    • Comprehensive data storage in case of failure.

    HIGH PERFORMANCE GENERAL PURPOSE DRIVE MD290

    • 4 to 500kW, Three Phase 380 to 480VAC.
    • Optional MODBUS-RTU, CANlink, Profibus-DP, CANopen.
    • Open loop V/F; Automatic torque boost.
    • 4-Independent S-Ramps
    • Output frequency 500Hz
    • Overload : 110% for normal duty and 150% for 60 Sec for heavy duty.
    • In-Built Dynamic braking unit upto 18.5kW
    • Built-in DC reactor EN61800-3 Category C2 2nd Environment.

    HMI IT7000

    • 3 Ph 380-480 Vac: 0.4 to 500 kW.
    • 3 Ph 200-240 Vac: 0.4 to 90 kW.
    • 1 Ph 200-240 Vac: 0.4 to 2.2 kW.
    • Operation in high ambient temperatures – up to 50degC.
    • Built-in DC reactor (400 V: 18.5 kW and above; 200 V: 11 kW and above.
    • Conformal coated PCBs compliant to 3S2 and 3C3 environments.
    • Complies to efficiency level IE2 as defined in IEC 61800-9-2.
    • Control modes: V/f for induction motor, Sensorless vector control (SVC), closed loop vector control (FVC) for both induction (asynchronous) and PMS motors.
    • Starting torque; 150% at 0.25 Hz for SVC; 180% at 0 Hz for FVC.
    • Communication options: Modbus-RTU, PROFIBUS-DP, CANopen, CANlink, PROFINET, EtherCAT, Ethernet/IP.
    • Brake control logic; inbuilt brake resistor upto 90kW.
    • Application dedicated functions: Centre winder, Textile wobble control, Master slave function. 4 motor parameter sets.
    • Bipolar analog input as standard (-10 to +10 V); PTC input as standard.
    • Output frequency: 599 Hz.
    • Encoder feedback (option): Incremental (HTL, Line Driver), Resolver, Serial encoder.

    PREMIUM INDUSTRIAL DRIVES ACS880

    • ACS880 drives are designed for customers who value high quality and robustness in their applications. coated boards and high enclosure classes, making the ACS880 suitable for harsh conditions.
    • Additionally, every ACS880 drive is factory-tested at full load to ensure maximum reliability.
    • The tests include performance and all protective functions.
    • Nine-year maintenance interval.
    •  ABB’s signature DIRECT TORQUE CONTROL (DTC), which provides precise speed and torque control for all applications and supports virtually any type of motor.
    • Global product approvals, e.g. CE, UL, cUL, CSA, marine certifications, ATEX, marine
    • Regenerative drives, ultra-low harmonics drives, liquid cooled drives,
    • Speed, torque and position control as well as synchronizing
    • Ready-made optimized solutions for various applications and industries
    •  Special application softwares for EOT cranes, tower cranes, winches, artificial oil lifting, tunnel ventilation, position control, textile, test bench, centrifuge, decanter,

    PREMIUM GENERAL PURPOSE DRIVES ACS580

    • 0.75kW to 500kW.
    • Part of all-compatible drives portfolio.
    • IP21, IP55, IP55 with switch and fuse.
    • Built-in features such as EMC C2 filter, choke, Modbus RTU fieldbus interface and safe torque off functionality.
    • The ATEX-certified thermistor protection module option CPTC-02.
    • IE2 drive (EN 50598-2) energy efficiency class, further reducing environmental impact.
    • ACS580 are compatible with high-efficiency IE4.
    • Side-by-side mounting, flange mounting and horizontal mounting are all available for wall-mounted ACS580 drives

    GENERAL PURPOSE DRIVES ACS560

    ACS560 General Purpose Drive Product Image

    • Ultra-fast 4.5 kHz current loop.
    • Safe Torque Off – SIL3.
    • High speed EtherCAT communications – 125 μs.
    • 23 bit High resolution feedback encoder.
    • Short output winding Standard, built-in, short output winding ensures safe braking if the drive is unexpectedly disabled – even in the case of a failure in the motor holding brake.
    • Comprehensive data storage in case of failure.

    MICRO MACHINERY DRIVES ACS380

    ACS380 Machinery Drive
    • 0.25kW to 22kW.
    • Part of all-compatible drives portfolio.
    • Built-in EMC filters.
    • IP20 enclosure and coated circuit boards.
    • Unique 3-phase measurement – reliable earth fault protection.
    • Galvanically isolated fieldbus gives good noise immunity.
    • Ambient temperature of up to 50°C without derating.
    • Foil coated control panel – protection against dust and gases.
    • Adaptive programming – sequential or block programming.
    • High starting torque, accurate speed control, stable torque or tolerance for sudden load variations with or without encoder feedback.
    • Simple positioning applications when using external motion controller.
    • Supports perfectly both induction and permanent magnet motors.
    • Silent motor operation with energy optimizer.
    • Fast stop functions and parabolic speed reference
    • Load profile log, which shows you how the drive has been used.

    MACHINERY DRIVES ACS180

    ACS180 machinery drive
    • 4 to 18.5kW.
    • Wide operating voltage: Three Phase 380VAC, 323 to 456VAC.
    • Onboard MODBUS & optional CANlink.
    • Open loop V/F & SVC control; Starting torque of 150% at 0.5Hz (SVC) and 100% at 1Hz (V/F); Automatic torque boost.
    • Simplified parameter for easy startup
    • 4-Independent S-Ramps
    • Output frequency 500Hz
    • Overload: 150% for 60 Sec & 180% for 3 Sec
    • In-Built Dynamic braking unit

    BASIC PLC H1U

    • All in one CPU and power supply supporting local and remote I/O.
    • 100 ns execution time per single, basic instruction.
    • Program capacity: 8 K steps.
    • Device memory
      • Auxiliary relays 3584 points
      • Timers 256 points
      • Counters 256 points
      • Data registers 8528 points
    • High speed inputs: up to 60 kHz.
    • High speed outputs: up to 100 kHz.
    • Supports RS485 (Modbus-RTU) and CANlink (Inovance proprietary) communication.
    • Maximum of 60 digital I/O (local), supports up to 30 remote modules (CANlink 3.0).
    • Programming language conforms to IEC 61131-3.
    • Ladder diagram (LD)/ Instruction list (IL)/ Sequential function chart (SFC).

    GENERAL PURPOSE MICRO DRIVE ACS200

      • 0.4 to 2.2kW single phase; 0.75kW to 3.7kW three phase.
      • Wide operating voltage : Single Phase 170 to 264VAC; 3-phase 323V to 528V.
      • Internal EMC Filter; complies with EN61800-3 Category C2 2nd Environment
      • Open loop V/F control; Staring torque of 150% at 3Hz; Automatic torque boost.
      • Modbus or CANLinkcomms
      • Output frequency 500Hz
      • Overload : 150% for 60 Sec & 180% for 3 Sec
      • In-Built Dynamic braking unit
      • Side-by-Side/ Wall Mounted/ DIN Rail Mounted

    MICRO MACHINERY DRIVES ACS355

    ACS355 Micro Drive Product Image

    • 0.25kW to 22kW.
    • Quick commissioning – application macros and panel assistants.
    • Safe torque off function (SIL3) as standard.
    • Sensorless vector control for induction motors and permanent magnet motors up to 599 Hz.
    • Built-in braking chopper.
    • IP66 and solar pump drive variant available.

    MICRO DRIVES ACS150

    ACS150 Micro Drive Product Image

    • Power range 0.37 to 4 kW/0.5 to 5 Hp
    • PID control, fixed keypad and speed control potentiometer
    • IP20 enclosure
    • Scalar control
    • Built-in brake chopper and Built-in EMC filter for 2nd environment
